RA-0501 - RA-1001 - RA-1501- RA-2501

WATER HEATERS FOR DIESEL ENGINES

500W, 1000W, 1500W, 2500W heaters that prevent the cooling circuit temperature from falling below a certain value. This value is controlled by an internal thermostat. Made of a rugged aluminum body, cataphoresis painted, making it resistant to the chemical components of the coolant liquid. The water circulates using the thermosiphon principle. Provided with connection with ½" BSP hole.

KEY FEATURES

- Temperature maintained by an internal thermostat.
- Can be mounted directly onto the engine.
- Easy connection via cable.
- Drain plug of the cooling liquid.
- Optimum dielectric strength (2000v).

IDENTIFICATION DATA

Type Power absorbed - Voltage   Code
RA-0501 500 W - 230V 1/2” BSP threaded hole 00706168
RA-1001 1000 W - 230V 1/2” BSP threaded hole 00706169
RA-1001/110 1000 W - 110V 1/2” BSP threaded hole 00706172
RA-1501 1500 W - 230V 1/2” BSP threaded hole 00706170
RA-2501 2500 W - 230V 1/2” BSP threaded hole 00706173

DOWNLOAD

Manual
Instruction and user manual RA-0500 - RA-1000 - RA-1500 - RA-0511 - RA-1011 - RA-501 - RA-1001 - RA-1501 - RA-2501
Instruction and user manual RA-0511/110 - RA-1001/110
