RA-0511 - RA-1011
WATER HEATERS FOR DIESEL ENGINES
500W, 1000W heaters that prevent the cooling circuit temperature from falling below a certain value. This value is controlled by an internal thermostat. Made of a rugged but small aluminum body, cataphoresis painted, making it resistant to the chemical components of the coolant liquid. The water circulates using the thermosiphon principle. Provided with connection with ½" BSP hole.KEY FEATURES
| - Temperature maintained by an internal thermostat. |
| - Can be mounted directly onto the engine. |
| - Easy connection via cable. |
| - Drain plug of the cooling liquid. |
| - Optimum dielectric strength (2000v). |
IDENTIFICATION DATA
| Type | Power absorbed - Voltage | Code | |
| RA-0511 | 500 W - 230V | 1/2” BSP threaded hole | 00706162 |
| RA-0511/110 | 500 W - 110V | 1/2” BSP threaded hole | 00706171 |
| RA-1011 | 1000 W - 230V | 1/2” BSP threaded hole | 00706164 |
