RA-0500 - RA-1000 - RA-1500

WATER HEATERS FOR DIESEL ENGINES

500W, 1000W, 1500W heaters that prevent the cooling circuit temperature from falling below a certain value. This value is controlled by an internal thermostat. Made of a rugged aluminum body, cataphoresis painted, making it resistant to the chemical components of the coolant liquid. The water circulates using the thermosiphon principle. Provided with connection with "hose connector".

KEY FEATURES

- Temperature maintained by an internal thermostat.
- Can be mounted directly onto the engine.
- Easy connection via cable.
- Drain plug of the cooling liquid.
- Optimum dielectric strength (2000v).

IDENTIFICATION DATA

Type Power absorbed   Code
RA-0500 500 W Fixed hose connectors 00706161
RA-1000 1000 W Fixed hose connectors 00706163
RA-1500 1500 W Fixed hose connectors 00706165

DOWNLOAD

Documents
Instruction and user manual RA-0500 - RA-1000 - RA-1500 - RA-0511 - RA-1011 - RA-501 - RA-1001 - RA-1501 - RA-2501
